EVA Collaborative Desktop Robot Arm

Parameters:

repeatability: ± 0.5 mm

max tool weight: 1.25 kg

reach: 600 mm

weight: 9.5 kg

max tool speed: 750 mm / second

power supply: 24 VDC 11.67A

power consumption: 280 W peak

mounting area: 160 x 160 mm

Interface:

4x analog input

2x analog output

6x digital input

6x digital output

1x E-Stop input

1x ethernet

1x Wifi card

tool power supply: 24 VDC @ 1 A

Environment:

IP20 protection

Temperature: 5 - 40 °C

Max humidity 40 °C: 50%

Max humidity 20 °C: 90%
